Vue-Gard® Safety Shield
Transparent Teflon shield allowing for 360° visual inspection of the joint while providing spray-out protection.
Vue-Gard®
The Vue-Gard® combines the superior chemical resistance of PTFE Teflon with a unique transparent construction that allows visual inspection of the flange joint - without removing the shield.
Material
Transparent PTFE (Teflon)
Maximum temperature
149°C (300°F)
Approvals
ABS Type Approval (SOLAS)
Custom sizes available
Contact usIs this the correct shield for your application?
Transparent pipe joint safety shields allow operators to inspect flange connections and identify leaks or deposits without removing the shield. They are particularly useful for neutral-pH fluids, where pH indicators may not change colour. Select shields based on pipe bore, flange class, connection geometry, operating pressure, temperature and chemical compatibility. Flange class alone does not determine shield performance. Safety shields help contain or redirect hazardous spray-outs but do not prevent gasket failure or replace inspection and maintenance.
Read the shield selection guideUnit prices in GBP, excluding shipping and VAT. Selected options are included in the table prices.
| SKU | Nominal Bore | Rating | Price | Quantity | Action |
|---|---|---|---|---|---|
| VUE-150-1/2 | 1/2" | 150lb | £22.13 GBP | ||
| VUE-150-3/4 | 3/4" | 150lb | £24.30 GBP | ||
| VUE-150-1 | 1" | 150lb | £25.72 GBP | ||
| VUE-150-1 1/4 | 1-1/4" | 150lb | £26.12 GBP | ||
| VUE-150-1 1/2 | 1-1/2" | 150lb | £27.82 GBP | ||
| VUE-150-2 | 2" | 150lb | £29.35 GBP | ||
| VUE-150-2 1/2 | 2-1/2" | 150lb | £32.05 GBP | ||
| VUE-150-3 | 3" | 150lb | £35.81 GBP | ||
| VUE-150-3 1/2 | 3-1/2" | 150lb | £38.22 GBP | ||
| VUE-150-4 | 4" | 150lb | £42.85 GBP | ||
| VUE-150-5 | 5" | 150lb | £47.56 GBP | ||
| VUE-150-6 | 6" | 150lb | £52.66 GBP | ||
| VUE-150-8 | 8" | 150lb | £58.06 GBP | ||
| VUE-150-10 | 10" | 150lb | £67.63 GBP | ||
| VUE-150-12 | 12" | 150lb | £79.13 GBP |
Vue-Gard® flange guard prices
Vue-Gard® costs from £22.13 GBP to £87.84 GBP per unit, depending on nominal bore and flange rating. Material: Transparent PTFE (Teflon). These are base catalogue prices excluding optional fittings, shipping and VAT. Select your rating, size and options in the order table; the basket calculates applicable shipping and VAT.
Key Benefits
- Prevents catastrophic spray-outs
- Protects personnel from chemical burns
- Reduces fire risk in flammable systems
- Meets international safety standards
Custom Configurations
We provide custom-fitted solutions for non-standard flanges and high-temperature applications.
Contact EngineeringExplore our full range of Safety Shields
Not sure which shield is right for your application? View all options below.
TFE Spra-Gard®
The industry standard for chemical resistance. Constructed of high-quality Teflon-coated fiberglass for maximum durability.
Metal Safety Shields (RAMCO Spray Control)
Heavy-duty 316 stainless steel flange safety shield with a quick-release clasp and integrated mesh layer, independently tested to 300 bar and DNV Type Approved for SOLAS.
